Digital Clamp Meters
Art.-No. 911-00044
| T2608-MET/PL
|
Copied
- Jaw Size 57 mm
- Min/Max
- Data hold/Peak hold
- Bargraph
- Auto power off
- Diode
- Continuity
Show more
Show less
More products in this product group:
| Application | Circuit measurements, safely measurements AC/DC current in wires without breaking the circuit (clamp around on coductor), voltage and resistance, check frequency |
| CAT-Rating | CATIII 1000V |
| Content Accessories | leads and case |
| Description | Clamp Meter Digital True RMS |
| Material | Metal (MET), Plastic (PL) |
| PART DESCRIPTION | T2608-MET/PL |
| Package Content | 1pc. |
| Package Content packed in | box |
| Part No. | T2608 |
| Power Supply | 9 V Battery |
| Product Family | T2608 2000 A DC/1500 A AC |
| Product Group | Digital Clamp Meters |
| Type | T2608 |
| Height (H) | 49mm |
| Length (L) | 277mm |
| Width (W) | 102mm |
Feature
[AC Current (A)]
Parameter
[400, 1500 A]
Accuracy
[±1.5% Digit(s)]
Feature
[AC Voltage (V)]
Parameter
[400 mV, 4, 40, 400, 750 V]
Accuracy
[±1.5% + 4 Digit(s)]
Feature
[Capacitance (F)]
Parameter
[4 nF, 40 nF, 400 nF, 4µ, 40 µF]
Accuracy
[±1.0% + 4 D Digit(s)]
Feature
[DC Current (A)]
Parameter
[400, 2000 A]
Accuracy
[±1.5% + 5 Digit(s)]
Feature
[DC Voltage (V)]
Parameter
[400 mV, 4, 40, 400, 1000 V]
Accuracy
[±0.5 % + 1 Digit]
Feature
[Frequency (Hz)]
Parameter
[10, 1k, 10k, 100k, 400 kHz]
Accuracy
[±0.1 % + 4 D Digit(s)]
Feature
[Resistance (Ω)]
Parameter
[400, 4K, 40K, 400K, 4M, 40 MΩ]
Accuracy
[±1.0 % + 4 Digit(s)]
| Feature | Parameter | Accuracy |
|---|---|---|
|
AC Current (A) |
400, 1500 A |
±1.5% Digit(s) |
|
AC Voltage (V) |
400 mV, 4, 40, 400, 750 V |
±1.5% + 4 Digit(s) |
|
Capacitance (F) |
4 nF, 40 nF, 400 nF, 4µ, 40 µF |
±1.0% + 4 D Digit(s) |
|
DC Current (A) |
400, 2000 A |
±1.5% + 5 Digit(s) |
|
DC Voltage (V) |
400 mV, 4, 40, 400, 1000 V |
±0.5 % + 1 Digit |
|
Frequency (Hz) |
10, 1k, 10k, 100k, 400 kHz |
±0.1 % + 4 D Digit(s) |
|
Resistance (Ω) |
400, 4K, 40K, 400K, 4M, 40 MΩ |
±1.0 % + 4 Digit(s) |
