Low-Heat Shrinkable Tubing 2:1 3.2/1.6 halogen free black
Art.-No. 302-30320 | TL27-3.2/1.6-PO-X-BK Details

  • Very low shrink temperature
  • Fast shrinking
  • Halogen free
Application TL27 has a low shrink temperature which offers very fast recovery. Application fields include covering of heat sensitive parts, mechanical protection and cosmetic covering.
Application Tool H6100
Behaviour At Low Temperature not cracking
Behaviour at Heat Shock not dripping, not fluid, not cracking
Behaviour at low Temperature test method UL 224
Colour Black (BK)
Elongation At Heat Aging 170%
Heat Aging Test 168h/136°C
Heat Aging test method SAE-AS23053
Heat Shock Test 4h/225°C
Material Polyolefin, cross-linked (PO-X)
Minimum Tensile Strength At Heat Aging 7.3MPa
PART DESCRIPTION TL27-3.2/1.6-PO-X-BK
Pack Cont. 300m
Package Content packed in reel
Part No. 30230320
Printable No
Product Family TL27
Product Group Heat shrinkable tubing 2:1 - Halogen free
Shrink Ratio 2:1
Size 1/8"
Type TL27-3.2/1.6
Variant Thin-Wall
With inner glue (Yes/No) No
Longitudinal Change After Shrinkage +5%/-15%
Recov. ∅ d max. 1.6mm
Supplied ∅ D min. 3.2mm
Wall (WT) 0.39mm
Dielectric Strength 23kV/mm
Dielectric Strength test method ASTM D876
ELV compliant (Article 4 - 2) YES
Elongation at break 400
Elongation at break test method ASTM D882
Halogen-free Yes
Hazardous Goods No
Min. Shrink Temperature - °C +90 °C
Operating Temperature -70 °C to +135 °C
ROHS compliant Yes
Self extinguishing Yes
Specifications
Tensile Strength 10.4MPa
Test Method Tensile Strength ASTM D882
Volume Resistance 10¹⁴ Ω cm
Volume Resistance test method ASTM D257
GTIN-13 / EAN 4031026221755
Packaging 1 - Height (m) 0.39m
Packaging 1 - Length (m) 0.39m
Packaging 1 - Qty 300
Packaging 1 - Type reel
Packaging 1 - Volume (m³) 0.01521
Packaging 1 - Weight (kg) 0.6kg
Packaging 1 - Width (m) 0.1m
Packaging 4 - Length (m) 1.2m
Packaging 4 - Qty 18000
Packaging 4 - Type pallet
Packaging 4 - Weight (kg) 93.0kg
Packaging 4 - Width (m) 0.8m
Reel Length 300.0m
UNSPSC Key 39121723
