Thermal transfer printer : TrakMark DS
Thermal Transfer Printer Double Sided Printing 300 dpi, Article number: 556-05000
Features
- High volume double sided printing
- Prints perfectly on HellermannTyton heat shrink ladder style products
- Uses standard 300 m ribbons
- Barcodes: standard and 2D
- Print speed up to 125 mm/s (30 mm/s recommended for ladder style products and tubing)
- Multiple language selection
- Windows drivers: 32/64 bit for Windows XP, Windows Vista, Windows 7, 8, 10
Certifications & Approvals
Application
The TrakMark DS is a high-performance printer for double-sided printing. This printer is perfect for double-sided printing on HellermannTyton shrinkable tubing. With two print heads mounted one on top of the other, the TrakMark DS prints onto both sides of the material at the same time. High reliability and multiple peripherals enable applications and solutions tailored to specific customer requirements. It is easy to use thanks to its display and clear status messages which can be shown in multiple languages. 300 dpi resolution ensures that barcodes, warning symbols, logos and text are as sharp as they can be.
TrakMark DS, Double Sided is suitable for following markets and industries
-
Automotive Industry
-
Electronics Industry
More products in this product group
Thermal transfer printer >| Colour | Grey (GY) |
| Features and Benefits | High volume two sided printing Max print width 105.6 mm Max print length 2000 mm Interfaces: USB 2.0 high speed slave for PC connection, Ethernet 10/100 Base T, LPD, RawIP printing, ftp printing, DHCP, HTTP, FTP, SMTP, SNMP, TIME, Zeroconf, mDNS, SOAP, Peripheral connection Options: External Reel Holder, Cutter (S4000), Perforator (P4000) Dimensions: 554 mm (D) x 395 mm (H) x 248 mm (W) Weight: 21 kg |
| Pack Cont. | 1pc. |
| Package Quantity per | EA |
| PART DESCRIPTION | TrakMark DS-MET-GY |
| Part No. | TRAKMARKDS |
| Print resolution DPI | 300 |
| Product Family | TrakMark DS, Double Sided |
| Product Group | Thermal transfer printer |
| Depth (D) | 554mm |
| Height (H) | 395mm |
| Label Height Max (metric) | 2000mm |
| Label Height Min (metric) | 6.35mm |
| Label Width Max (imperial) | 4.25" |
| Label Width Max (metric) | 105.6mm |
| Label Width Min (imperial) | 0.65" |
| Label Width Min (metric) | 16.51mm |
| Length (L) | 533.4mm |
| Print Method | Thermal transfer |
| Width (W) | 248mm |
| CSA Certified | No |
| ELV compliant (Article 4 - 2) | YES |
| Hazardous good | No |
| Interfaces | RS232 C, USB 2.0, Ethernet 10/100 Base T |
| Material | Metal (MET) |
| Material | MET |
| Max. Print Width | 105.6mm |
| Max. Print Width | 4.16" |
| Operating Temperature - °C | +4 °C to +40 °C |
| Print Head Type | 300 dpi, flat type |
| Print Speed | 30, 40, 50, 75, 100, 125 mm/s |
| Printer Memory | 64MB RAM |
| Specifications |
|
| Specifications | 2004/108/EG, 2014/35/EU, ANSI/UL 60950-1, ANSI/UL 60950-21, ANSI/UL 60950-22, ANSI/UL 60950-23, EN 55022:2011-12, EN 55024:2011-09, EN 61000-3-2, EN 61000-3-3, EN 61000-6-2, FCC |
| Supported Barcodes, Printer | Standard, 2D |
| Supported Consumables | Shrinkable Wire Markers: Continuous Tubing – TLFX, TULT, TCGT; Ladder Style – TULT DS, TLFX DS Cable Bundle Tags: Continuous - TIPTAG, TIPTAG PU |
| UL Listed (US and Canada) | Yes |
| UL Recognized (US and Canada) | No |
| UL-File Number | MH18396 |
| Dimensions W x H x D | 248 mm x 395 mm x 554 mm |
| EAN / GTIN | 4031026321783 |
| Packaging 3 - Height (m) | 0.463m |
| Packaging 3 - Length (m) | 0.772m |
| Packaging 3 - Qty | 1 |
| Packaging 3 - Type | carton |
| Packaging 3 - Volume (m³) | 0.1147m³ |
| Packaging 3 - Weight (kg) | 21.5kg |
| Packaging 3 - Width (m) | 0.321m |
| Packaging 4 - Length (m) | 1.2m |
| Packaging 4 - Qty | 6 |
| Packaging 4 - Type | pallet |
| Packaging 4 - Weight (kg) | 150.0kg |
| Packaging 4 - Width (m) | 0.8m |
| Weight | 21kg |
| Weight | 46.2lbs |
| UNSPSC Key | 39131505 |
