Cable tie inside serrated, 101.6x2.5mm, ∅1.5-22.0mm, blue, 100pcs.
Art.-No. 111-02070 | T18R-PA66-BU Details

  • Avaliable in a wide range of material and sizes
  • Made from 100% high quality plastic, allows for good recycling
  • Inside serration for a strong hold onto bundles
  • Easy application either manually or with a processing tool
  • Simple to insert due to bent tail
Show more
e-Learning
Application T-Series cable ties for bundling and securing of cables, pipes and hoses. These cable ties can be used for nearly all kind of applications.
Colour Blue (BU)
Description CABLE TIES INSULOK 100 x 2.5mm BLUE
Identification Plate Position none
Material Polyamide 6.6 (PA66)
PART DESCRIPTION T18R-PA66-BU
Pack Cont. 100pcs.
Package Content packed in bag
Part No. T18RBL
Product Group Cable ties polyamide 6.6 standard
Releasable Closure (Yes/No) No
Tie Closure plastic pawl
Type T18R
Variant Inside Serrated
Bundle Diameter max (metric) 22.0mm
Bundle ∅ min. 1.5mm
Cable Tie Head Length (metric) 4.8mm
Cable Tie Head Width (metric) 4.45mm
Height (H) 3.7mm
Length (L) 101.6mm
Min.Tensile Strength 80N
Strap Width max. (G) 0.18"
Thickness (T) 1.0mm
Width (W) 2.5mm
Flammability UL 94 V2
Halogen-free Yes
Operating Temperature -40 °C to +85 °C
ROHS compliant Yes
Specifications
GTIN-13 / EAN 6005242036330
UNSPSC Key 39121703
