Identification Tag halogen free white 15x65 mm
Art.-No. 556-21069 | TIPTAG15X65WH-PO-WH Details

  • Ideal for marking larger wire and cable bundles
  • Halogen free
  • Low smoke propagation and toxicity
  • Perforated format that includes fastening slots for cable ties
  • Available in various colours
Show more
e-Learning
Application The Tiptag HF cable markers have been designed to identify larger wires and cable bundles not only in the electronics and general cabling environments but also in the railway industry. Tiptag HF is halogen free and its material properties show low smoke propagation, density and toxicity. Tiptags are presented in a special perforated format which include fastening slots for easy fitting with cable ties. They are also suitable for retrofit purposes. Print from the reel with HellermannTyton's premium range of thermal transfer printers and ribbons for optimum print quality and longevity.
Application Tool TT431, TT4030
Colour White (WH)
Fixation Method Others
Material Polyolefin (PO)
Pack Cont. 190pcs.
Package Content packed in reel
PART DESCRIPTION TIPTAG15X65WH-PO-WH
Part No. 55621069
Product Family TIPTAG HF – Rail Limited Fire Hazard, Halogen free
Product Group Identification tags for cable bundle, thermal transfer
Self adhesive (Yes/No) No
Variant Roller form
With label space Yes
Length (L) 65.0mm
Print Method thermal transfer print
Print Method (Alternative) laser beam print
Width (W) 15.0mm
ELV compliant (Article 4 - 2) YES
EN 45545-2 Results R22 HL3, R23 HL3
Halogen-free Yes
Hazardous Goods No
Limited Fire Hazard Yes
Operating Temperature -40 °C to +90 °C, (+160 °C, for 200 h)
Recommended Ribbon Type TTDTHOUT
Reel Variant continuous
Specifications
Specifications EN 45545-2
GTIN-13 / EAN 4031026171784
Packaging 1 - Height (m) 0.1m
Packaging 1 - Length (m) 0.16m
Packaging 1 - Qty 190
Packaging 1 - Type bag
Packaging 1 - Volume (m³) 0.00022
Packaging 1 - Weight (kg) 0.220001kg
Packaging 1 - Width (m) 0.014m
