Heat shrink marker, thermal transfer print, ladder-style, 6.4mm/3.2mm, W=50mm, yellow, 3000pcs.
Art.-No. 553-60013 | TLFX64DS-1x50YE-PO-X-YE Details

  • Shrink ratio 2:1
  • Halogen Free
  • Low smoke propagation, density and toxicity
  • 50 mm, 25 mm and 16 mm pre-cut marker options as standard
  • Available in yellow or white
  • Other lengths and colours available on request
  • Cable range 38.1 mm to 1.2 mm
  • Delivery in convenient storage boxes
Show more
Application TLFX DS is a halogen free European rail approved 2:1 heat shrink marker material supplied pre-cut and formatted into a convenient "ladder" system. Special material properties show low smoke propagation, density and toxicity. This pre-cut format not only allows printing on both sides of the marker but the user can also easily choose and pick each required marker. Special material properties show low smoke propagation, density and toxicity. The tubing has been especially prepared so that the print performance is excellent at all times using HellermannTyton's printer range.
Application Tool H6100, TT431, TT4030, TT4030DS
Colour Yellow (YE)
Fixation Method Suspend
Material Polyolefin, cross-linked (PO-X)
Pack Cont. 3000pcs.
Package Content packed in carton
Part No. 55360013
Printable Yes
Product Family TLFX DS – 2:1 Rail Limited Fire Hazard "Ladder Style"
Product Group Shrinkable markers "Ladder Style", thermal transfer
Shrink Ratio 2:1
Variant Roller form
With inner glue (Yes/No) No
With label space No
Height (H) 50.0mm
Longitudinal Change After Shrinkage -5% max.
Longitudinal Change After Shrinkage test method UL 224
Print Method thermal transfer print
Print Method (Alternative) laser beam print
Recov. ∅ d max. 3.2mm
Recov. ∅ d max. 0.125"
Supplied ∅ D min. 6.4mm
Supplied ∅ D min. 0.25"
Wall (WT) 0.725mm
Wall (WT) 0.029"
Width (W) 50mm
Width printable 25.40mm
Dielectric Strength 20kV/mm
Dielectric Strength test method ASTM D2671
Elongation at break 200 %
Elongation at break test method ASTM D2671
ELV compliant (Article 4 - 2) YES
EN 45545-2 Results R22 HL3, R23 HL3
Flammability UL 224
Halogen-free Yes
Hazardous Goods No
Limited Fire Hazard Yes
Min. Shrink Temperature - °C +100 °C
Operating Temperature -55 °C to +105 °C
Recommended Ribbon Type TTDTHOUT
Reel Variant ladder-style
Shelf Life 5 years
Specifications ASTM 1354, ASTM E 162, ASTM E 662, EN 45545-2, NFPA 130 compliant
Tensile Strength 11MPa
Test Method Tensile Strength ASTM D2671
GTIN-13 / EAN 4031026321554
Markers per row 1
Packaging 1 - Height (m) 0.12m
Packaging 1 - Length (m) 0.318m
Packaging 1 - Qty 3000
Packaging 1 - Type bag
Packaging 1 - Volume (m³) 0.01271
Packaging 1 - Weight (kg) 2.900001kg
Packaging 1 - Width (m) 0.333m
UNSPSC Key 39131502
